TY - 120   TY - 250
  Spindle center   ( A ) M. T. 2#   3#
    ( B ) J. T. 2 1/2 #   2 1/2 #
  Max drilling ability   16   25
  Spindle center stroke   93   130
  Distance between worktable surface and spindle center   420   630
  Distance between a base and spindle center   620   930
  Outer diameter of a post   80   102
  Outer diameter of round plate and round shape   320   420
  Height of drilling machine   1080   1540
  Use motor   1HP   2HP
  Rotational speed   Changing speed   4   6

Rotational speed per minute
  50HZ   480 - 1980   200 - 1600
    60HZ   560 - 2100   210 - 1700
  Weight   Without a motor   79   173
    With a motor   95   198










TY - 350
  Spindle center   M .T.4#
  Max drilling ability   35
  Spindle center stroke mm   153
  Distance between main spindle and worktable   max725   min180
  Working area mm   435
  Motor   3HP * 8/4p
  Rotational speed changing speed   8
  Rotational speed range   50 HZ   127 - 961
    60 HZ   150 - 1140
  Speed changing of plunge   0.10 , 0.12 , 0.15   0.20 , 0.24 , 0.30
  Machine weight       492
