TYPE

Vertical type
       TY - 190
  Wieght

  200 kg

Main spindle stroke
       110 mm

Rotary diameter
       430 mm

Thread diameter
      19

Up and down moving distanceof the head
      300 mm

Distance between main spindle and worktable
      160 - 460 mm

Worktable dimension
      340 * 340
  Basic area

Motor
       ( 1HP ) 0.75 kw - 4p

Main spindle revolution RPM
  50HZ
375,625,1,080,1,670

    60HZ
450,7501,300,2,000


The suitable automatic feeding pitch for this machine: Each machine is equipped with a change gear. The above-said specification is available.
  thread per inch   Range 10 - 100
Speed 40m
Pressure 5k
    mm
